2-6
C7-621 / C7-621 AS-i Control Systems
C79000-G7076-C622-01
You select the C7 CPU modes menu in the system function menu by
pressing the

key.
The following menu is displayed (the MODE: STOP is an example):
= Anwahl der
DIR–Funktion
Currently
selected
mode
Keys for
selecting
further modes
MODE:STOP
RUNP RUN STOP MRES
    
Figure 2-4 “C7 CPU Modes” Menu and Function Keys
Selecting the Mode
Menu
Startup
