Parameterizing the Mobile Panel
5.6 Control Panel
Mobile Panels 2nd Generation
94 Operating Instructions, 09/2018, A5E33876626-AC
Alphanumerical screen keyboard
The alphanumerical screen keyboard has the following levels.
● Normal level
– HMI device with 4" display
– HMI device with 7" display diagonal or larger
Note
The ' character on the keyboard is only displayed when followed by a space. If the '
cha
racter is followed by a letter, then the result will be an accent, such as "á".
● Shift level
The shift level has uppercase letters and other special characters.
The alphanumeric keyboard is always displayed after a restart.
Numerical screen keyboard
By pressing the "Num" button, you can switch between the numerical and alphanumerical
screen keyboard.
You activate the reduced screen keyboard with the key. The minimized screen keyboard
is displayed as follows:
