Commissioning the device
4.3 Parameter assignment for Comfort Panel
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
81
Representation types for the screen keyboard
You can toggle the screen keyboard display as follows.
Alphanumerical screen keyboard
The alphanumerical screen keyboard has the following levels.
● Normal level
– HMI device with 4" display
– HMI device with 7" display diagonal or larger
The ' character on the keyboard is only displayed when followed by a space. If the '
character is followed by a letter, then the result will be an accent, such as "á".
● Shift level
The shift level has uppercase letters and other special characters.
The alphanumeric keyboard is always displayed after a restart.
Numerical screen keyboard
By pressing the "Num" button, you can switch between the numerical and alphanumerical
screen keyboard.
