Dimension drawings
7.1 Dimension drawings
RS 485 Repeater
40 Manual, 02/2011, A5E03382072-01
RS 485 repeater on mounting rail
The figure below shows the dimensional drawing of the RS 485 repeater on an S7-300
mounting rail.



Figure 7-2 RS 485 repeater on standard rail
