Valores de torque para ensamble de capuchones y deflectores
TORNILLO CABEZA HEXAGONAL GRADO 5
Diámetro
Pulgadas
Hilos por
pulgada
Min
(Nm)
Nominal
(Nm)
Max.
(Nm)
3/16"
24
3.0
3.5
3.8
3/16"
24
3.0
3.5
3.8
3/16"
24
3.5
4.0
4.5
1/4"
20
8.0
10.0
13.0
3/8"
16
20.0
24.0
28.0
3/8"
16
25.0
30.0
35.0
7/16"
14
50.0
55.0
60.0
7/16"
14
55.0
60.0
65.0
3/8"
16
18.0
22.0
26.0
3/8"
16
20.0
24.0
28.0
3/8"
16
25.0
30.0
35.0
Valores de torque para ensamble de cajas conexiones
TORNILLO CABEZA HEXAGONAL GRADO 5
Diámetro
Pulgadas
Hilos por
pulgada
Min
(Nm)
Nominal
(Nm)
Max.
(Nm)
1/4"
20
5.0
7.5
10.5
5/16"
18
11.0
14.0
17.0
3/8"
16
16.0
20.0
24.0
1/2"
13
21.0
26.0
30.0
