Grease Quantity per End-Shield (oz)
NEMA Frame
Drive
End.
Opp. Drive
End.
140
0.1
0.1
180
0.2
0.2
210
0.3
0.3
250
0.5
0.5
280
2.6
2.6
320
5.5
5.5
360
7.5
7.5
400
7.5
7.5
440
14.5
7.5
S449
14.5
7.5
500
14.5
7.5
Table 1.3 Grease Quantities.
VERTICAL MOTORS THRUST BEARINGS
Top Bearings. High external thrust from the driven unit is usually carried
by the top bearing or bearings. If replacement is necessary, the new bearing
must be the same size and type as the original.
Duplex bearings must also be the same type and mounted in an identical
manner. When angular contact type bearings are replaced, the new bearing
must have the same thrust capacity.
Bottom bearings. For an adequate lubrication It is important to maintain
the lower cavity full of grease at all times.
The re-lubricating procedure for vertical motors is the same as outlined
above under “Lubrication procedure”.
The correct replacement bearings are given on the nameplate by AFBMA
(Anti-Friction Bearing Manufacturers Association) number.
