Supplementary system components
6.5 CX32-2 controller extension
SIMOTION D4x5-2
Manual, 02/2012
125
Ambient conditions
The following conditions apply to modules that are shipped and stored in the original
packaging.
Table 6- 30 CX32-2 environmental requirements
Parameter Values
Permissible ambient temperature
• Transport
• Long-term storage
• Operation
• -40° C ... +70° C
• -25° C ... +55° C
• 0° C ... +55° C up to 2000 m above sea level.
As of an altitude of 2000 m, the maximum
ambient temperature decreases by 7° C every
1000 m increase in altitude
Atmospheric pressure 620 ... 1060 hPa
Permissible relative humidity
• During transport and storage
• During operation (condensation, icing, drip,
spray and splash water not permitted)
• 10 % ... 100 %
• 5 % ... 90 %
Installation altitude Max. 4000 m above sea level.
For SINAMICS S120 drive components, see
SINAMICS Manuals.
Biological environmental conditions
• Storage
• Transport
• Operation
• Class 1B1 according to EN 60 721-3-1
• Class 2B1 according to EN 60 721-3-2
• Class 3B1 according to EN 60 721-3-3
Degree of protection according to EN 60529
(IEC 60529)
IP20
Pollution degree 2 according to EN 60 664-1
Integrated drive control
Table 6- 31 Controls for integrated drives
Data SIMOTION CX32-2
Max. number of axes for integrated drive
control (servo/vector/
V
/
f
)
6 / 6 / 12 (alternative)
drive control based on SINAMICS S120 CU320-2,
firmware version V4.x
