Description
1.5 Representation of SIMOTION D425-2 DP/PN and D435-2 DP/PN
SIMOTION D4x5-2
Manual, 02/2012
25
CAUTION
SIMOTION D425-2 DP/PN and D435-2 DP/PN must be operated with a double fan/battery
module for heat dissipation. Without this module, the Control Units will not start up and
cannot be commissioned.
Information on how to install the double fan/battery module can be found in "Supplementary
system components", in Section Installing the fan/battery module (Page 95).
Note
The SIMOTION D425-2 DP/PN and D435-2 DP/PN are supplied with pre-assembled
spacers. They can be removed if necessary.
For further details, see the
SIMOTION D4x5-2
Commissioning and Hardware Installation
Manual.
