SINAMICS V50 infrastructure drives for HVAC/Water/Wastewater
37 kW to 250 kW (50 to 400 hp)
SINAMICS V50 infrastructure drives for HVAC/Water/Wastewater
Selection and ordering data
SINAMICS
V
50
drives Degree of protection IP20/UL Open Type 380 ... 480 V 3 AC Configuration with line
-
side
components (see right page)
Rated
power
)
Rated
output
current

)
Base
−
load
current
I


)
Rated
input
current

)
Frame
size
SINAMICS V50
Degree of protection
IP20/UL Open Type
without integrated line filter
400V 480V 400V 480V 400V 480V 400V
kW hp A A A A A
Article No.
380…480V 3AC Rated pulse frequency 4kHz≤90kW, 2kHz for 110kW to 250kW Input frequency 47…63 Hz
37 50 75 65 60 52
68
FSD
6SL36
0- YE36- U 0
45 60 90 77 75 65 84 FSE
6SL36
0- YE38- U 0
55 75 110 96 90 77 103 FSE
6SL36
0- YE40- U 0
75 100 150 129 115 101 134 FSF
6SL36
0- YE42- U 0
90 125 176 154 143 122 162 FSF
6SL36
0- YE44- U 0
110 150 210 185 183 161 205 FSF
6SL36
0- YE46- U 0
132 200 250 240 205 180 233 FSF
6SL36
0- YE48- U 0
160 250 300 300 248 238 281 FSG
6SL36
0- YE50- U 0
200 300 380 371 312 312 350 FSG
6SL36
0- YE52- U 0
250 400 470 470 363 354 409 FSG
6SL36
0- YE54- U 0
Article No. supplements
Environmental class/harmful chemical substances acc. to IEC 60721-3-3: 2002
Class 3C2 – delivery ex stock
2
Class 3C3 *
3
Operator Panel
With BOP-3 Basic Operator Panel (numeric display)
4
Extension with SINAMICS V50 I/O Extension Module
Without extension – delivery ex stock
0
Line filter
Without integrated line filter – delivery ex stock
U
Communication
USS, Modbus RTU, BACnet MS/TP
B
