Siemens SIRIUS 3RS17 Series User Manual

Bestell-Nr. / Order No.: 3ZX1012-0RS17-0AW1 3
3RS1706-.FD00/-.FE00/-.FW00
16 IN / 3 OUT
IN: (S1) Pos. 0-F
OUT: (S2) 0-10 V 0-20 mA 4-20 mA
Power: AC/DC 24 V
AC/DC 24 V-240 V
• - > Switch On S2
Output 1234
0-10 V •
0-20 mA •
4-20 mA •
S1 S1
Input Pos. Input Pos.
0-60 mV 0 0-20 V 8
0-100 mV 1 2-10 V 9
0-300 mV 2 0-5 mA A
0-500 mV 3 0-10 mA B
0-1 V 4 0-20 mA C
0-2 V 5 4-20 mA D
0-5 V 6 ±5 mA E
0-10 V 7 ±20 mA F
IV)
6
OUT+
5
OUT-
1
IN+
2
IN-
6
OUT
5
0 V
1
IN+
2
IN-
7
Power
8
7
Power
8
U, I
U, I
U, I U, I
3RS1706-.FD00
3RS1706-.FE00
3RS1706-.FW00
3RS170. – 1 . . 00 3RS170. – 2 . . 00
Ø 3,5 x 0,6 mm / DIN ISO 2380
0,5 ... 0,8 Nm
Ø 3,5 x 0,6 mm / DIN ISO 2380
—
0,5 ... 2,5 mm²
AWG 20 to 14
0,5 ... 2,5 mm²
AWG 20 to 14
—
0,5 ... 2,5 mm²
AWG 20 to 14
0,5 ... 2,5 mm²
AWG 20 to 14
0,5 ... 1,5 mm²
AWG 20 to 16
8
6 - 7
6 -7
8
6 - 7
I ... IV)
1
2
3
3RS170.-.AD00 / -.CD00 / -.DD00
3RS170.-.AD0.-0..0
6,2
1
2
3
4
5
80,0
84,0
79
1
)
80
2
)
3RS17.5-.FD00 / -.KD00
1) 3RS17..-1..00
2) 3RS17..-2..00
3RS1720-.ET00
12,5
5,6
1,2
3,4
7,8
12,5
1,2
3,4
80,0
84,0
79
1
)
80
2
)
3RS1722-.ET00
3RS1721-
.ET00
3RS172.-.ET00
17,5
1,2,3
4,5,6
7,8,9
3RS1705-
.FW00 / -.KW00
3RS1706-
.FD00 / -.FE00 / -.FW00
80,0
84,0
79
1
)
80
2
)
17,5
1,2,3
4,5,6
7,8,9
5
7
3RS1725-.FD00 / . -.FW00
3RS170.-....
