3ZX1012-0TK28-4DA1 7
DE
Das Sicherheitsschaltgerät 3TK2826 können Sie in NOT-
HALT Einrichtungen nach EN 418 und in
Sicherheitsstromkreisen nach EN 60 204-1 verwenden,
z. B. bei beweglichen Verdeckungen und Schutztüren bzw.
bei berührungslos wirkenden Schutzeinrichtungen nach
IEC 61496-1.
Der erreichbare PL bzw. SIL ist von der ext. Beschaltung
abhängig.
Unter Berücksichtigung der Umgebungsbedingungen
müssen die Geräte in Schaltschränke der Schutzart IP32,
IP43 oder IP54 eingebaut werden.
Verschmutzungsgrad 3
Weitere Informationen und Techn. Daten siehe Handbuch
oder Produktdatenblatt 3TK2826
www.siemens.com/industrial-controls
Klemmenbelegung
A1 L/+
A2 N/-
13,14; 23,24; 33,34; 43,44 Freigabekreis (FK) Relais, Schließer
51,52 Meldekreis (MK), Relais, Öffner (Status FK)
64 (nur 3TK2826-.BB40) MK elektronisch 24 V DC; Rückführkreis-Fehler (RF)
74 (nur 3TK2826-.BB40 MK elektronisch 24 V DC; (Sensorstatus)
63,64 (nur 3TK2826-.CW30) MK Relais Schließer; Rückführkreis-Fehler (RF)
T1,T2 Testausgänge
T3 Sensorversorgung 24 V DC;
1 Kaskadiereingang / betriebsmäßiges Schalten
Y11,Y22 Sensoreingang Kanal 1, Kanal 2
Y33 Starttaster (Start nach Aufwärts- und Abwärtsflanke)
Y34 Rückführkreis(RF)
EN
You can use the 3TK2826 safety relay in EMERGENCY
STOP devices according to EN 418 and in safety circuits
complying with EN 60204-1, e.g. for moving covers and
protective doors or for electro-sensitive protective
equipment conforming to IEC 61496-1.
The PL or SIL that is obtainable depends on the external
wiring.
In view of the ambient conditions, relays with degrees of
protection IP32, IP43 or IP54 must be installed in the
cabinets.
Pollution degree 3
For further information and technical data, see the manual
or product data sheet 3TK2826
www.siemens.com/industrial-controls
Terminal assignment
A1 L/+
A2 N/-
13,14; 23,24; 33,34; 43,44 Enabling circuit (EC) relay, normally-open, undelayed
51,52 Signaling circuit (SC), relay, normally-closed (EC status)
64 (only 3TK2826-.BB40) SC solid-state 24 V DC; return circuit fault (RF)
74 (only 3TK2826-.BB40) SC solid-state 24 V DC; (sensor status)
63,64 (only 3TK2826-.CW30) SC, relay, normally-open; return circuit fault (RF)
T1,T2 Test outputs
T3 24 V DC sensor supply
1 Cascading input/normal switching duty
Y11,Y22 Sensor input channel 1, channel 2
Y33 Start button (start after rising and falling edge)
Y34 feedback circuit
FR
Le bloc logique de sécurité 3TK2826 est utilisable dans des
dispositifs d'ARRÊT d'URGENCE selon EN 418 et dans des
circutis de sécurité selon EN 60204-1, par exemple avec
des protecteurs mobiles ou dans des équipements de
protection électro-sensibles selon IEC 61496-1.
Le niveau PL ou SIL réalisable dépende des circuits
externes.
Les appareils doivent être intégrés dans des armoires
ayant le degré de protection IP32, IP43 ou IP54 selon les
conditions d'environnement.
Degré de pollution 3
Pour de plus amples informations et pour les
caractéristiques, voir manuel ou fiche du produit 3TK2826
www.siemens.com/industrial-controls
Affectation des bornes
A1 L/+
A2 N/-
13,14; 23,24; 33,34; 43,44
Circuit de validation (CV) relais, NO, instantané
51,52 Circuit de signalisation (CS), relais, NF (état CV)
64 (uniquemen 3TK2826-.BB40) CS électronique 24 V CC ; défaut circuit de retour (RF)
74 (uniquemen 3TK2826-.BB40) CS électronique 24 V CC ; (état du capteur)
63,64
(uniquemen 3TK2826-.CW30)
CS relais NO ; défaut circuit de retour (RF)
T1,T2 Sorties test
T3 Alimentation du capteur 24 V CC
1 Entrée en cascade / manœuvre de service
Y11,Y22 Entrée de capteur voie 1, voie 2
Y33
Touche de démarrage (démarrage après front montant et front
descendant)
Y34 circuit de réaction
