7 Functional test
The Functional Test ensures the proper operation of the device. In case the
Functional Test is not successful even after inserting a new HDD, the devices shall
be sent to the Service Centre.
7.1 Preconditions
The following point need to be checked before starting the Functional Test:
z Connect the power supply (make sure that the power supply is stable)
z Recording for the Functional Test for minimum 2 hours
z If the firmware of the device needs to be upgraded, the Functional test shall be
performed after the firmware upgrade.
For the Functional Test, the device shall be configured as follows:
z Recording mode: “Overwrite” (“Recycle” in AX8/AX16 500/200))
z Recording rate: “25 ips”
z Image quality: “Very high”
z Panic recording: “On”
7.2 Test procedures
Perform the following tests in the normal operating mode.
Test# Action Test
1 Power on the device.
Verify booting of the device. LEDs
illuminated?
2
Connect all video input channels to video
signals.
Connect a monitor to the video outputs
(BNC and VGA).
Switch monitor to display the live image
of all cameras.
Verify video input and video output signals.
3
Switch on the Panic recording mode for
at least 2 hours.
Start recording.
4
Stop Panic recording mode and search
for recorded images in the Search menu.
Verify recorded video.
5 Access the “Storage” menu in the OSD. Verify HDD parameters.
6 Access System Log.
Verify system log in regards to errors or
reboots of the system.
