Technical data
11
Siemens AG
06.2010
3 Technical data
Monitoring
Video inputs Composite: 4 looped through, BNC, PAL/NTSC (auto detection)
Video outputs 1 Composite (BNC)
1 VGA: 800 x 600, 1024 x 768, 1280 x 1024 (60 Hz)
Video resolution 720 x 576 (PAL), 720 x 480 (NTSC)
Display mode 1, 4, Sequence, Digital Zoom, Freeze, Covert
Inputs/Outputs
Audio inputs 4 line level RCA
Audio output 1 line level RCA
Alarm inputs 4, NC or NO, TTL
Alarm outputs 1 relay output, NC or NO, 2 A (125 V AC), 1 A (30 V DC)
Alarm reset input 1
Network Ethernet (10/100 BaseT)
Interfaces Front buttons, mouse, remote keyboard, IR remote control, RAS software
Auxiliary inputs/outputs RS232, RS485, USB 2.0
Internal buzzer 80 dB at 10 cm
Record/Playback
Compression H.264 technology (video), ADPCM (audio)
Recording speed Standard resolution: up to 100 ips (PAL), 120 ips (NTSC)
High resolution: up to 50 ips (PAL), 60 ips (NTSC)
4CIF resolution: up to 25 ips (PAL), 30 ips (NTSC)
Recording resolution CIF, 2CIF, 4CIF
Recording mode Time-Lapse, Event, Pre-Event (up to 30 min.), Text-In, Panic
Search mode Date/Time, Calendar, Event, Motion, Museum, Text-In, Record Table
System
Operating system Embedded Linux (built-in flash memory)
Hard disk capacity 1 internal hard disk drive: 1000 GB SATA
Backup recording media USB (hard disk drive, CD burner, flash memory)
Disk management Temperature check, SMART diagnosis, operation without hard disk drive
