Operation
91
Siemens AG
06.2010
8. Highlight the box beside Record Channels and press the button.
Î You can select the cameras that you want to search for any reports of event
recorded data. The DVR will display the events (not the camera channels) that
occurred and that also are recorded on the camera channel that you selected. If
you do not select a camera channel in this field, the DVR will search events that
are not associated with cameras.
Î You can also toggle On and Off self-diagnostic events as part of your search.
The choices are:
– Panic Record
– Check Recording
– Check Alarm-In
– Disk Almost Full
– Disk Bad
– Disk Temperature
– Disk S.M.A.R.T.
– Fan Error
Î Once you set your desired search conditions, highlight Search and press the
button to display the search results in the Event Log Search screen.
Î Selecting Cancel exits the screen without saving the changes.
8.7.1.2 Record Table Search
Fig. 95 Record table search screen (Compact View)
Fig. 96 Record table search screen (Standard View)
Fig. 97 Record table search screen (Expanded View)
Recording information about video images currently displayed on the screen
displays on the recording status bar. A white vertical line indicates the current search
position. To search specific video, move the vertical line by using the Left or Right
arrow buttons on the front panel or by clicking the mouse on the desired segment.
If the DVR’s time and date have been reset to a time that is earlier than some
recorded video, it is possible for the DVR to have more than one video stream in the
same time range. In this case, the overlapping time range in the record table will be
separated by a yellow vertical line.
