Siemens AG Österreich 7 of 8 SITOP power DC-UPS Module 15
Tabelle 1: Ladeschlussspannungen bei anderen Akku-Temperaturen
Table 1: End-of-charge voltage for other battery temperatures
Akkumodule/Battery: 6EP1935-6MD11, 6EP1935-6ME21, 6EP1935-6MF01
-10°C
29,0V
0°C
28,4V
10°C
27,8V
20°C
27,3V
25°C
27,0V
30°C
26,8V
35°C
26,7V
40°C
26,6V
Akkumodul/Battery: 6EP1935-6MD31
-10°C
29,0V
0°C
28,6V
10°C
28,3V
20°C
27,9V
25°C
27,7V
30°C
27,5V
35°C
27,4V
40°C
27,2V
45°C
27,0V
50°C
26,8V
60°C
26,4V
Tabelle 2: Einstellbare Pufferzeiten
Table 2: Adjustable buffering time
gewünschte Buffering time / buffering time [s]
5 15 25 35 45 55 65 75 85 95 105 115 125 135 145 155 165 175 185 195 205 215 225 235 245 255 265 275 285 295 305 315 max
111111111111111111111111111111110
00000000000000001111111111111111x
00000000111111110000000011111111x
00001111000011110000111100001111x
00110011001100110011001100110011x
01010101010101010101010101010101x
X 400
On ←
2
3
4
5
6
Schaterstellung: On = 1 ; Off = 0 ; x = kein Einfluss, d.h. wenn Schalter 1 auf Pos Off ist, puffert das USV-Modul bis zur Tiefentladeschwelle
Switch position: On = 1 ; Off = 0 ; x = Irrelevant, i.e. if switch 1 is in Pos Off, the UPS module buffers the supply until the exhaustive discharge threshold is reached
