Siemens WM16W570EE - Hose and Cable Lengths

Positioning and connecting en
41
1. Take the hoses out of the holders.
2. Unscrew and remove all four
transport brace screws.
Remove the sleeves. To do this,
remove the mains cable from the
holders.
3. Insert the covers. Lock the covers
firmly in place by applying pressure
to the snap-in hooks.
Hose and cable lengths
■ Left-hand connection
■ Right-hand connection
Tip: The following are available from
specialist dealers/customer services:
■ Extension for Aqua-Stop and cold
water supply hose (approx. 2.50 m);
order no. WM Z2380, WZ 10130,
CZ 11350, Z 7070X0
■ A longer supply hose
(approx. 2.20 m) for standard
models; individual component
number for customer services:
00353925
