A selection of glues - SIG Thin and Thick CA and
SIG Kwik-Set 5-Minute Epoxy
Threadlock Compound, Such as Loctite
®
Non-Permanent Blue
Silicon Sealer - clear or white tub and shower type
Screwdriver Assortment
Pliers - Needle Nose & Flat Nose
Diagonal Wire Cutters
Small Allen Wrench Assortment
Pin Vise for Small Dia. Drill Bits
Hobby Knife With Sharp #11 Blades
Scissors
Heat Iron and Trim Seal Tool
Masking Tape
Paper Towels
Glass Cleaner,
such as SIG Pure Magic Model Cleaner or Windex
®
Power Drill With Selection of Bits
Dremel
®
Tool With Selection of Sanding and Grinding Bits
Soldering Iron and Solder
Large Fuel Tubing
COMPLETE KIT PARTS LIST:
The following is a complete list of all parts contained in this kit.
Before beginning assembly, we suggest that you take the time to
inventory the parts in your kit, using the provided check-off boxes
( ❑ ). Note that the CA type hinges for the ailerons, rudder, and
elevators are in place in each of these parts but are not
yet glued
in place. Also, note that the nuts and bolts required to mount your
engine to the motor mounts are not
included in this kit and must be
purchased separately.
BASIC AIRCRAFT PARTS:
❑ 1 each Right
Wing Panel With Aileron in Place With
4 CA Hinges - Not Glued Aileron Servo Cable String
Installed - Factory Covered
❑ 1 each Left
Wing Panel With Aileron in Place With
4 CA Hinges - Not Glued Aileron Servo Cable String
Installed - Factory Covered
❑ 1 each Vertical Fin & Rudder Assembly With
4 Hinges - Not Glued Factory Covered
❑ 1 each Horizontal Stabilizer & Elevator Assembly With
6 Hinges - Not Glued Factory Covered
❑ 1 each Fuselage With Clear Plastic Windshield Installed
With 7 Screws. 4 Landing Gear Blind Mounting Nuts
Installed, Installed 1/4-20 Blind Mounting Nuts For
Wing Attachment, 2 Wing Strut Attachment Blind Nuts
Installed, Pull-Pull Exits Installed - Factory Covered
SUB ASSEMBLIES:
❑ 1 bag Fiberglass Cowl, White:
❑ 4 each #3 x 10mm PWA Mounting Screws
❑ 1 bag Fiberglass Wheel Pants - 1 Right
, 1 Left - Factory
Painted (Blue/White or Red/White) With Blind
Mounting Nuts Installed (2 per pant) for Mounting
❑ 1 bag 3” Dia. White SIG Spinner Assembly:
❑ 1 each Spinner Cone
❑ 1 each Spinner Backplate
❑ 1 each Prop Adapter Ring Set
❑ 4 each #2 x 10mm
Phillips Head Mounting Screws
❑ 1 bag Molded Clear Plastic Side Window Set
❑ 1 bag Motor Mount Assembly:
❑ 2 each
Fiber-Filled Motor Mount Arms - 1 Right, 1 Left
❑ 4 each M4 x 25mm PWA Mounting Bolts
❑ 4 each M4 Washers
❑ 4 each M4 Split Ring Lock Washers
❑ 4 each M4 Blind Mounting Nuts
❑ 1 bag Fuel Tank Assembly:
❑ 1 each 450cc (15.2 oz.) Fuel Tank
❑ 1 each Fuel Pick-Up “Clunk” - Metal
❑ 1 each 4-1/2” Length of Fuel Tubing (for glow
engines only)
❑ 1 each Rubber Fuel Tank Stopper (for glow
engines only)
❑ 1 each Front Stopper Compression Plate
❑ 1 each Rear Stopper Compression Plate
❑ 1 each
M3 x 18mm Phillips Head Compression Bolt
❑ 3 each 3mm Dia. Aluminum Tube Fuel Lines:
❑ 1 @ 40mm Long
❑ 1 @ 50mm Long
❑ 1 @ 60mm Long
❑ 1 bag SIG Tailwheel Assembly - Medium:
❑ 1 each
Main Tailwheel Spring Arm With Steering
Arm & 1-1/4” Dia. Tailwheel Installed
❑ 1 each Secondary Tailwheel Spring Arm
❑ 1 each 2-Arm Rudder Steering Plate - Metal
❑ 2 each #2 X 10mm PWA Steering Plate
Mounting Screws
❑ 3 each #3 x 15mm PWA Tailwheel Assembly
Mounting Screws
❑ 2 each Centering Springs
❑ 1 bag Main Landing Gear Assembly:
❑ 1 each Landing Gear, 4mm Hardened
Aluminum – Factory Painted White
❑ 2 each 3-1/2” Dia. Main Wheels - “Lite”-Type
❑ 2 each M5 x 50mm Hardened Steel Allen Head
Axle Bolts
❑ 4 each M5 Hex Nuts
❑ 2 each M5 Split Ring Lock Washers
❑ 2 each M5 Brass Spacer Sleeves
❑ 4 each M4 x 20mm PWA Main Landing Gear
Mounting Bolts
❑ 4 each M4 Split Ring Lock Washers
❑ 4 each M3 x 12mm Phillips Head Wheel Pant
Mounting Bolts
❑ 4 each M3 Split Ring Lock Washers
❑ 1 bag Wing Strut Assemblies:
❑ 1 each Right
Wing Strut, Aluminum, With
Contoured End Caps Installed -
Factory Painted White
❑ 1 each Left
Wing Strut, Aluminum, With
Contoured End Caps Installed -
Factory Painted White
❑ 4 each M3 x 20mm Allen Head Mounting Bolts
❑ 4 each M3 Washers
❑ 4 each M3 Split Ring Lock Washers
❑ 1 bag Aileron Servo Hatch Assemblies & Wing Bolts:
❑ 1 each Right
Aileron Hatch, Plywood - Factory
Covered
❑ 1 each Left
Aileron Hatch, Plywood - Factory
Covered
❑ 4 each 10mm x 20mm sq. (3/8" x 3/4" sq.)
Hardwood Aileron Servo Mounting Blocks
❑ 8 each #3 x 10mm PWA Servo Hatch Mounting
Screws
❑ 4 each #2 x 8mm PWA Mounting Block Screws
❑ 2 each
1/4-20 x 1-1/2” Nylon Wing Mounting Bolts
3
