SIGLENT SDG2042X Quick Start

SDG2000X Quick Start-8
Waveforms ---- Ramp
Provide ramp waveform output which ranges from 1μHz to 1MHz.
•The backlight of Waveforms will turn on when this function is selected.
•“Frequency/Period”, “Amplitude/High level”, “Offset/Low level”, “Phase” and “Symmetry” of the ramp waveform can be adjusted.
Waveforms ---- Pulse
Provide pulse waveform output which ranges from 1μHz to 25MHz.
•The backlight of Waveforms will turn on when this function is selected.
•“Frequency/Period”, “Amplitude/High level”, “Offset/Low level”, “Pulse width/Duty”, “Rise/Fall” and “Delay” of the pulse waveform can be adjusted.
Waveforms ---- Noise
Provide White Gauss Noise output with a bandwidth of 120MHz.
•The backlight of Waveforms will turn on when this function is selected.
•“Stdev” and “”Mean” of the noise signal can be adjusted.
Waveforms ---- Arb
Provide arbitrary waveform output which ranges from 1μHz to 20MHz.
•The backlight of Waveforms will turn on when this function is selected.
•Support two output modes: “DDS” and “TrueArb”.
•Built-in waveforms include Cardiac, Gauspuls, ExpRise and ExpFall, etc. In addition, the output waveform stored on the U-Disk can be outputted.
•Users can edit arbitrary waveforms through EasyWaveX and download them to the instrument.
•“Frequency/Period”, “Amplitude/High level”, “Offset/Low level” and “Phase” of the arbitrary waveform can be adjusted.
11.Menu Keys
These keys correspond to the menu displayed above them on the display. Press any key to activate the corresponding menu.
