SDG2000X Quick Start-4
1.Power Key
This key is used to turn on/off the SDG2000X. When the power key is off, SDG2000X is in the power off state.
2.USB Host
SDG2000X supports U-Disk using FAT format. It’s used to read waveforms or state les from a U-Disk or store the current state of the instrument to the U-Disk.
Users can update the rmware through U-Disk.
3.Touch Screen Display
SDG2000X has a 4.3 inch TFT-LCD touch screen, which displays current function menu, parameter settings, system state, prompts, etc. It is the most important
display and control center of the instrument. For detailed information, please refer to “Touch Screen Display”.
4.Numeric Keyboard
Consists of numbers from 0 to 9, radix points “.” and symbol keys “+/-”, which are used to input parameters.
Note
：
To enter a negative number, you need to enter a symbol “-” at rst.
5.Knob
It is used to increase (clockwise) or decrease (counterclockwise) the current numerical value when setting parameters.
It is also used to switch characters in the soft keyboard when inputting a le name.
When saving or reading les, rotate the knob to choose a position to save a le or choose a le to be read; press the knob to open a selected folder or le.
When choosing Waveforms
→
Page 1/2
→
Arb
→
Arb Type rotate the knob to select a desired built-in or stored waveform.
6.Arrow Keys
When using knob to set parameters, they are used to select the digit to be modied.
When using numeric keyboard to set parameters, the left arrow key is used as a Backspace function.
When inputting a le name, they are used to move the position of cursor.
