Sigma CHEF 10 - Page 16

Instructions manual CHEF 10 VVE
16 of 19
SPARE PARTS LIST TABLE:
Position Quantity Code Description
1 1 199080 BMC-10 INVERTER UPPER CASING
2 1 199038-1 BMC-10 INVERTER MOTOR PULLEY
3 1 BMC-10 “J” BELT 790 5 RIB
4 1 199039-3 BMC-10 INV. CONDUIT PULLEY
5 1 199019 BMC-10 PLANETARY SHAFT
6 1 25001301 CROUZET “GRID” MICRO SWITCH PLUS
LEVER
7 1 199021 BMC-10 TOOL HOLDER SHAFT
8 1 199022 BMC-10 PLANET AND CROWN GEARS
9 2 BEARING 6206 (62-30-16)
10 1 199024 BMC-10 INTERNAL CROWN WHEEL
11 1 199023 BMC-10 CONTAINMENT BOWL
12 1 199020 BMC-10 PLANETARY
13 1 199032 BMC-10 GRID UNIT
14 1 BMC-10 BK2526 ROLLER BUSHING WITH
CAP
15 1 098109-2 BMC -10 BOWL
16 1 MIM 25-47-10
17 2 BEARING 6205 2RS (25-52-15)
18 1 098162
098164
098165
BMC-10 WHISK UNIT
BMC-10 CAST SPIRAL
BMC-10 CAST BLADE
19 2 098030-2 BOWL LIFTING GUIDE BLADES
20 1 DELTA INVERTER -VFD004S1A-
21 1 MV15 MICRO SWITCH
22 1 G71 4P 0,55 Kw B14 MOTOR
23 1 199071 REDUCING UNIT SUPPORT
24 1 199070 REDUCING UNIT ATTACHMENT SHAFT
25 1 199068 BM-CHEF-10 SCREW FOR REDUCTION
UNIT
26 1 199069 BM-CHEF-10 CROWN WHEEL
REDUCTION UNIT
27 2 13000004 BEARING 6004 2RS 20-42-12
