SIGMATEK CCP 521 User Manual

C-DIAS PROCESSOR MODULE CCP 521
15.03.2016 Page 11
Connector
Type
Wire Size
Max. drive torque
X1
USB Typ Mini-B
-
-
X2
USB Typ A
-
-
X3, X4
RJ45
-
-
X5
B2L 3.5/6
0.13 - 1.0 mm
2
28 - 18 AWG (UL/CSA)
Cage Clamp
X6
FK-MCP 1.5/ 2-ST-3.5
0.14 - 1.5 mm
2
28 - 16 AWG (UL/cUL)
Cage Clamp
MC 1.5/ 2-ST-3.5
0.13 - 1.0 mm
2
,
30 - 16 AWG (UL),
28 - 16 AWG (CSA)
0.22 - 0.25 Nm
Applicable connectors
USB Device: 5-pin, type Mini-B
USB Host: 4-pin, type A
Ethernet: 8-pin, RJ45
VARAN: 8-pin, RJ45
CAN-Bus: 6-pin Weidmüller plug, B2L3,5/6
Supply: 2-pin Phoenix plug with screw terminal technology MC 1.5/ 2-ST-3.5
2-pin Phoenix plug with spring terminal FK-MCP 1.5/ 2-ST-3.5
The complete C-DIAS CKL 017 connector set with spring terminals is available from
Sigmatek under the article number 12-600-017.
