CCP 521 C-DIAS PROCESSOR MODULE
Page 2 15.03.2016
Technical Data
Performance data
Processor
EDGE-Technology X86 compatible
16-bit data bus
Clock frequency
500 MHz
Addressable I/O/P modules
VARAN bus: 65.280
CAN bus: 32
C-DIAS bus: 8
Internal I/O
No
Internal cache
32-kbyte L1 Cache
256-kbyte L2 Cache
BIOS
AMI
Internal program and data memory (DDR2
RAM)
64 Mbytes
Internal remnant data memory
512 Kbytes
(1)
Internal storage device (IDE)
512 MByte microSD card
Interface connections
1 x USB Host 2.0 (full speed 12 Mbit/s)
1 x USB Device 1.1
1 x Ethernet
1 x CAN
1 x VARAN-Out (Manager) (maximum length: 100 m)
1 x C-DIAS
Data buffer
Yes
Status display
Yes
Status LEDs
Yes
Real-time clock
Yes (buffering approximately 10 days)
(1)
See chapter “Note on SRAM Behavior”
