Signal Hound SM200C User Manual

Understanding the SM-series Hardware | Front End Architecture
20
Optional Preselector Filters
Filter
Range used for Sweeps
(MHz)
Useable Range for I/Q
streaming
Bypass Filter
(Preselector Off)
0 (LPF)
0-19.5
0-40
160 MHz LPF
1
19.5-29.3
19-31
160 MHz LPF
2
27-36
23.8-39
160 MHz LPF
3
36-47
33-52
160 MHz LPF
4
47-63
42-68
160 MHz LPF
5
63-92
59-100
160 MHz LPF
6
92-136.7
86-146
160 MHz LPF
7
136.7-198
130-210
110 MHz HPF
8
198-293
190-303
110 MHz HPF
9
293-410
280-440
110 MHz HPF
10
410-644.5
400-645
110 MHz HPF
Always-On Preselector Filters (SM200)
Filter
Frequency Range used for Sweeps
11
644.5 - 957 MHz
12
957 - 1465
13
1465-1855
14
1855 - 2400
15
2400 - 3260
16
3260 - 4460
17
4460 - 6150
18
6150 - 8180
19
8180 - 10960
20
10960 - 14000
21
14000 - 20000
