SM200 Specifications | Zero Span (IQ Streaming)
29
5
Displayed Average Noise Level (DANL)
LO Leakage at RF Input -82 dBm from 100kHz to 5GHz
-55dBm from 5GHz to 10GHz
-50dBm from 10GHz to 18GHz
-47dBm from 18GHz to 20GHz
5
Residual Responses (Ref Level ≤ -20 dBm, 0 dB Attenuation, 50-ohm load on RF input)
Input Frequency Range
Residual Level (dBm)
100 kHz to 80 MHz
-110
80 MHz to 15 GHz
-100
15 GHz to 20 GHz
-90
5
Spurious Responses (any ref level (RL) from +10dBm to -20dBm, in 5dB increments, input 10 dB
< RL, RBW ≤ 30kHz, 40MHz IBW)
Input Freq. Range
Image Reject Off (dBc)
Image Reject On (dBc) typical
100 kHz to 6 GHz
-58
-75
6 GHz to 10 GHz
-55
-75
10 GHz to 20 GHz
-44
-75
Sub-Octave Filtered Preselector 20MHz to 20GHz
Input Frequency Range
dBm/Hz
100 kHz to 700 MHz
–156 dBm
700 MHz to 2.7 GHz
–160 dBm
2.7 GHz to 4.5 GHz
–158 dBm
4.5 GHz to 8.5 GHz
–153 dBm
8.5 GHz to 15 GHz
–154 dBm
15 GHz to 20 GHz
–149 dBm

Signal Hound SM200C Specifications

General

Brand	Signal Hound
Model	SM200C
Category	Measuring Instruments
Language	English
