Signal Hound SM200C User Manual

SM435 Preliminary Specifications | Zero Span (IQ Streaming)
34
5
SSB Phase Noise at 1 GHz Center Frequency
Offset Frequency
dBc/Hz
10Hz
-76
100 Hz
-108
1 kHz
-125
10 kHz
-136
100 kHz
-138
1 MHz
-138
5
SSB Phase Noise at 20 GHz Center Frequency
Offset Frequency
dBc/Hz
1MHz
-112
10 MHz
-131
Synchronization GPS data in each packet with ± 40ns time-stamping
FPGA Altera 10AX027 has 1660 multipliers, provides
selectable decimation, 160MHz of instantaneous
bandwidth from FFT processing, and has resources to
spare for future growth
Connectivity
4
Local external computer with Microsoft Windows or
Ubuntu Linux and one USB3.0 port is required to
operate the SM435B (minimum of Intel 3
rd
Gen i7
processor or equivalent).
GPIO Port Used for antenna switching and in/out triggering
GUI Languages English, Simplified Chinese, Dutch, French, German,
Italian, Japanese, Russian, and Spanish
8
Operating Temperature Standard: 32°F to 122°F (0°C to +50°C) passive cooling
(ambient)
Option 1: -40°F to 149°F (-40°C to +65°C) active cooling
& extended temperature
6
Size 10.45” x 7.2” x 2.15” (259mm x 183mm x 55mm) passive
cooling
10.45” x 7.2” x 2.74” (259mm x 183mm x 70mm) active
cooling
Weight 8.15 lbs. (3.70 kg) passive cooling (Standard)
