Signal Hound VSG60A User Manual

VSG60A Preliminary Specifications | Inputs / Outputs
9
Spectral Purity
Harmonics
50 MHz to 6 GHz, CW, 0 dBm
< -30 dBc
Image Response
50 MHz to 6 GHz, -10 dBm,
20 MHz modulation bandwidth
< -40 dBc
50 MHz to 6 GHz, -10 dBm,
40 MHz modulation bandwidth
< -30 dBc
Carrier Feedthrough
50 MHz to 6 GHz, CW, 0 dBm
< -40 dBc
SSB Phase Noise
1 GHz CW, 0 dBm
10 kHz offset
100 kHz offset
< -120 dBc/Hz
< -122 dBc/Hz
Other non-harmonic Spurious
Carrier 50 MHz to 6 GHz
Digital tuning enabled
Modulated with 1 MHz tone
Level -10 dBm,
Spurs measured to 1.7x center
frequency
< -40 dBc
Error Vector Magnitude (EVM)
(-10 dBm output power)
QPSK, 4 MS/s, 0.2RRC
< 3 GHz
3-6 GHz
QAM16, 4 MS/s, 0.2 RRC
< 3 GHz
3-6 GHz
1 GHz QAM16, 1 MS/s, 0.35 RC
< 1.2% (typ. 0.6%)
< 1.8%
< 1.0% (typ. 0.5%)
< 1.7%
< 0.5% (typ. 0.3%)
Adjacent Channel Power Ratio
(RRC 0.2, -10 dBm)
QPSK 4 MS/s, 5 MHz channel
< 3 GHz
3-6 GHz
< -50 dBc (typ. -55 dBc)
< -40 dBc (typ. -45 dBc)
INPUTS / OUTPUTS
Data and Power (1) USB 3.0 port and (1) adjacent USB 2.0 or USB 3.0 port
RF output SMA (F)
External 10 MHz Input BNC (F), 0 to +13 dBm recommended
Trigger Output BNC (F), 3.3V logic level
