MODEL: EA1440 PRODUCT CODE: 6619 04/2019
08
Product Overview (cont.)
1. Crosshair (symbol for Aim or Target)
2. Mode of Measurement:
•
- Set for rainy conditions, when measuring objects beyond 60m.
•
- Set to measure close objects as a priority.
•
- Set to measure far objects as a priority.
• No Icon - Standard conditions.
3. Distance Measurement (in metres or yards)
4. Quality of Measurement:
• This indicator refers to the current quality of measurement under the
current conditions. Please continue to select the appropriate Mode of
Measurement until six bars "
" or more are shown on the lens
display. If under six bars are shown, the return-wave (the strength and
quality of the reception between the device and the object) will not be
strong enough to measure and display the distance.
5. Low Battery Indicator
6. Laser Emission Indicator
Lens Display
