Signode PSD-109 - Parts List; Main Frame, Lever, and Dancer Arm Spring Assembly Parts

16
PARTS LIST
MAIN FRAME, LEVER ASSEMBLY AND DANCER ARM SPRING ASSEMBLY
KEY QTY. PART NO. DESCRIPTION
1 1 426364 Spring housing cap
2 1 426365 Spring housing liner
3 1 426366 Post
5 4 426368 Hex head cap screw, 5/16-24 x 3/4
6 6 426369 Lockwasher, 5/16
8 1 426371 Hex head cap screw, 3/8-16 x3
9 1 426372 Lockwasher, 3/8
10 1 426373 Flatwasher, 3/8
11 1 426374 Flatwasher, 5/16
12 1 426375 Base plate
13 1 426376 Elastic stop nut, 3/8-24, thin
14 4 426378 Hex head cap screw, 5/16-24 x 1
15 1 426379 Hex nut, 5/16-24
16 1 426380 Brake cam follower, 3/4 dia.
17 1 426381 Retaining Ring, external, 3/4
18 1 426382 Flat Washer, 1/2
19 1 517766 Hex head cap screw, 1/2-20 x 3 3/4
20 1 517765 Brake block
21 1 510379 Brake lever
22 1 426386 Elastic stop nut, 1/2-20, thin
23 1 510378 Brake lever pivot
24 1 426388 S-Hook
25 1 517767 Brake Spring
30 1 426390 Hex nut, 3/8-16
62 1 426391 Dancer arm compression spring
63 1 426392 Spring bushing
64 1 426393 Spring stud
65 1 426394 Eye bolt
66 1 426395 Hex nut, 1/4-20
71 1 510380 Bushing
• When ordering parts, please show model, part number and name.
• Common hardware parts may be obtained at any local hardware supply.
