PSD-109 ACCUMULATING DISPENSER
RIGHT-HAND PAYOFF (P/N 513684)
LEFT-HAND PAYOFF (P/N 513685)
TABLE OF CONTENTS
General Safety Instructions 2
Introduction 3
Specifications 3
Major Components 4
Installation 5
Coil Loading Instructions 5
Operation 6
Adjustments 7
Parts Removal & Replacement 9
Troubleshooting 13
Parts List 16
INTRODUCTION
This dispenser is to be used with power strapping equipment only. It is tension actuated and
multi-roller design can accumulate 30 feet of retracted strap available at an actuation force of 5
pounds.
SPECIFICATIONS
MODEL STRAPPING
PSD-109
TYPE WIDTH COIL SIZE
Polyester
or
Polypropylene
Up to 16mm 24"OD x 16"ID x 6"W
