PARTS LIST, Continued
BRAKE CAMSHAFT ASSEMBLY
KEY QTY. PART NO. DESCRIPTION
5 4 426368 Hex head cap screw, 5/16-24 x 3/4
6 4 426369 Lockwasher, 5/16
43 2 426412 Flanged cartridge bearing, 1 dia.
44 2 426413 Bearing alignment plate
46 1 426415 Actuation chain
49 2 426418 Retaining ring, external, 1
51 1 426420 Sprocket key
52 2 426423 Socket head machine screw, 10-24 x 5/8
53 2 426424 Lockwasher, #10
58 2 426431 Flat Washer, #10
59 1 426432 Brake Cam
60 1 426433 Brake cam shaft
61 1 426434 Camshaft sprocket
• When ordering parts, please show model, part number and name.
• Common hardware parts may be obtained at any local hardware supply.
