4
Speakers
HDMI display
Transmitter
CE-H21V11-S1
Figure 2: Application
CAT5e cable
(up to 200ft)
Transceiver
CE-H21W11-S1
Speakers
CAT5e cable to
Transceiver or
Receiver
HDMI
source
HDMI cable
Power adapter
Power adapter
Application
HDMI display
