Osiris-Jaegar – Installer Guide
Presets
Each preset allows you to define a camera pan and tilt position as well as a zoom setting. You can define up
to 128 presets which can then be either accessed using a Goto command, selected from the Goto Preset
menu or can be linked together within one or more camera tours.
When you choose the Presets option within the menu, the list of presets will be shown. The ‘@’ suffix
indicates that the corresponding preset has position data stored within it.
If the Prest value is assigned to a function (Ref. Appendix 5) this will be indicated with an “f” suffix.
If the set position is beyond a user limit for Pan, Tilt (or both) it will be indicated with a suffix “p”, “t” or “b”.
Edit preset…
001@ 002f 003f 004f 005f
006f 007f 008f 009f 010f
011f 012f 013f 014f 015f
016f 017f 018f 019 020@
021 022 023 024 025
026 027 028 029 030
031 032 033 034 035
036 037 038 039 040
041 042 043 044 045
Scroll downwards to view further items.
Highlight the required preset number and select it to view the available options:
Osiris Open Platform
Version n.nnn (xxxx) xx
SN: FFFFFFFF POST: 000000000
Preset 1
Store preset
Erase preset
Exit menu
Store preset saves the current camera pan/tilt/zoom position in the selected preset.
Erase preset clears the location stored within the selected preset.
Special Feature Presets.
For installations of PAIR2 enhanced lenses preset positions 130c – 139c are assigned for lens functions.
These presets are masked to record the PAIR2 enhancement settings that are active at the time of recording
and not other parameters such as the position of the PT unit.
Recalling these presets will cause the lens enhancement settings to adjust to the recorded values whilst not
initiating any PTZ actions.
Privacy Zones
Privacy zones functionality is presently unavailable.
Silent Sentinel SilSen DN145003 - 1.2b (Fork)
10
