Osiris-Jaegar – Installer Guide
Appendices
Appendix 1 – Extended functions
The base preset number (OSD Menu) can be set in the Configuration menu (the default is 2) for use with
controllers of limited preset numbering all functions have fixed location preset value that can be used to
initiate them.
The currently defined functions are:
Preset No. Extended Functions
1 Fixed 1 Select - when in menus and preset 1 otherwise.
2 (Default)
Base Value Fixed 199
Menu
3 (Default)
Base+1 Fixed 200
Night Mode (Mono)
4 (Default)
Base+2 Fixed 201
Wiper function
(Do not wipe when window is dry.)
5 (Default)
Base+3 Fixed 202
Aux 1
6 (Default)
Base+4 Fixed 203
Aux 2
7 (Default)
Base+5 Fixed 204
Video Swap
(Only for twin camera modules)
8 (Default)
Base+6 Fixed 205
Magnifier
9 (Default)
Base+7 Fixed 206
Secondary Imager Control [SIC]
(Only for twin camera modules)
10 (Default)
Base+8 Fixed 207
PAIR Enhancement View
(Only applicable to PAIR DSP lenses.)
11 (Default)
Base+9 Fixed 208
Wide Dynamic Range – On/Off toggle.
(Applicable models only)
12 (Default)
Base+10 Fixed 209
Auto-focus (for keyboard without AF key)
13 (Default)
Base+11 Fixed 210
Auto-Iris (for keyboards without AI key)
14 (Default)
Base+12
White LED - On/Off toggle
(Only applicable to White LED equipped models.)
15 (Default)
Base+13
End Mimic Recording
(Only if during Mimic recording.)
16 (Default)
Base+14
ICE On/Off
(Only for Thermal Image models.)
17 (Default)
Base+15
ICE Level Increase
(Only for Thermal Image models.)
18 (Default)
Base+16
ICE Level Decrease
(Only for Thermal Image models.)
- Fixed 197 Re-enters the boot screen to show protocol and switch settings
- Fixed 198 Quick Installation Menu
If CAM2 Control [SIC] is to the Secondary (Thermal) camera, the Iris controls will be assigned to alternative
functions:-
Iris open(+) – Digital Enlargment – cycles through values.
Iris close(-) – Thermal Polarity – Toggles White-as-hot / Black-as-hot.
