Osiris-Jaegar – Installer Guide
Communications
Silent Sentinel Oculus
Version n.nnn (xxxx) xx
SN: FFFFFFFF POST: 000000000
Camera number 1
Protocol PelcoD
Auto-protocol On
PelcoD mode Traditional
Baud rate 9600
Data-bits 8-bits
Parity None
Stop-bits 1
Exit menu
Default values shown.
Camera number sets the protocol address for the camera. Default is Camera 1 – selected in firmware
menu. (Range 1 - 255)
Protocol sets the RS485 protocol. The protocol will not be changed until the camera is rebooted.
Auto-protocol selects whether the camera will automatically select a protocol to match the incoming control
commands. The camera can detect OCP/CBC, Pelco-D, Pelco-P and Vicon formats.
PelcoD Mode selects the format used fir Pelco D telemetry. Traditional mode applies suppresses responses
to General commands. Strict mode uses ACK responses and modified Zoom and Tilt coordinate data values.
Baud rate, Data-bits, Parity and Stop-bits are used to configure the RS485 serial port and should be
adjusted only if necessary.
Default settings are Pelco-D, 9600. 8 bit data, No parity, 1 Stop-bit.
