20
COPYRIGHT SILENTRON DFVPho neBasicX B07 0116GM
SILENTRON - ITALIA
Display Operation Par.
VOCAL
MESSAG E 1
Confirm ↵.
VOCAL
MESSAG E 1
↵ RECORDING
Keep arrow ↵ pressed to record the first vocal message. The display will show the availabl e ti me left (total
time 120 sec .). Release ↵ to sto p t he op eration a nd to aut omatic ally list en t o t he message whic h h as just
been rec orded. To canc el: CANC., ot her wise E SC.
VOCAL
MESSAG E 1
Use ↕ t o go do wn t o mess ag es 2, 3, 4, and in partic ular to 5 (g uiding message), or press ESC to exit.
VOCAL
MESSAG ES
GSM models: ↓ for SMS MESSAGES. Proce dure : se e VOC AL MESSAG ES.
10 Writable SMS of max 24 char acters. To exit press ESC until the display will show MESSAGES. Go down
with ↓ to TOOLS.
TOOLS Radio models: ↵. 5.3
VOCAL
RADIO CODES
↵. Menu t o programme t he radio c od es.
VOCAL
RADIO CODE 1
↵. Sub menu t o programme t he codes of voc al message 1. Eac h o f t he 4 voc al messages has a s ep arate
submenu.
↵ TO
PROGRAMME 1
Confirm with ↵. Su bmenu of th e 1st. radio c od e of the 1s t. vocal mess ag e. E ach vocal mess ag e has 10
possible radio codes.
VOCAL
RADIO CODE 1
PERIPHERAL 1
VocalPhone will await transmission of the radio code of the peripher al for t he 1st. ch annel of the 1st. vocal
mess ag e. The position h ere d escribed is normally res er ved to the control unit. Let th e ra dio periph eral
transmit (see s pecific i nstructions):
- Control unit: do not us e re mot e control or keypad. For instanc e: make el ectrical connection b et ween KEY
and GND.
- Detector an d panic key of t he ke yp ad: i nsert t he ba tter y.
- Blue or yellow ke y of the remote co ntrol: keep pr essed for 10 s ec.
- Red a nd g reen keys of the remote c ontrol (bist abl e): press both t he keys at the s a me ti me.
MEM. VOC. CODE 1
CONTROL UNIT 1
Confirmation: beep ♫ + dis play s ho wing the n° of the mess ag e (from 1 to 4), the t ype of perip heral
memorized (control panel, detec tor, remote c ontrol) and p osition (from 1 t o 10). Confirm with ↵.
VOCAL
RADIO CODE 1
↵ CONFIRMATION
Also enter f urther radio cod es f or th e s ame message and f or the o ther 3 mess ag es (use ↕), or exit (ESC).
Model 5 46 1: go down until SMS RADI O COD. t o a ppl y t he same procedure as with radio codes. Press ESC
to exit when ended.
TOOLS Go down with ↓.
SETTINGS Confirm with ↵. Att enti on: the following s ub menus are availabl e depending on the models. 5.4
RELAY
SETTINGS
↵. Adjust ment o f t he parameters o f the relay for actuations o f hous e automations . Also see par. 6.6 f or the
confirmations of th e ac tuations fro m dist anc e.
5.4. 1
Example :
IMPULSIVE
T : 2 SEC.
Select IMPULSI VE or ON-OFF (bistable) wit h ↕. In c ase of IMPULSI VE, enter the l aps e of ti me require d
bet we en 1 and 999 sec. C onfirm wit h ↵. Repeat the same operation with submenu TC2 SETTINGS.
RADIO COMMANDS Radio models: ↵. 5.4. 3 -
6.6
RADIO COMMAND 1 ↵. (16 A vaila ble c ommands for hous e aut omation ac tuations via ra dio).
DETECTOR Choos e b et we en DET ECTOR and REMOTE CONTROL with ↕:
- DETECTOR: monos tabIe R X2 (see sp ecific instr uctions).
- REMOTE CONTROL: ON-OFF on control unit (see 6.1 for the TECHNICAL SMS 4 and 5) or
bistabl e o n RX2 (RX2 incl udes a cr epusc ular sensor and allo ws ho use aut omation actuations
220V 8A mp.).
Put t he control u nit a /o the RX2 i n programmi ng-status (see specific instruc tions) f ollo we d from ↵ to enter
the radio code. The control unit will confirm (♫) a/o RX2 will stop flashing.
RADIO COMMAND 1 Use ↕ for other radio co mman ds (from 1 to 16), or E SC to exit.
RADIO COMMANDS ↓.
GSM-PHONE LINE ↵, Followed from ↕ to s elect priority of the calls. C onfirm wit h ↵. The display will return to GSM-PHONE
LINE. Go down with ↓.
5.4. 4
ABSENCE PO WER
SUPPLY
↵.
Example:
ABSENCE PO WER
SUPPLY
N
T: 30 min.
Message of abs enc e of power su ppl y: en abl e or less wit h ↕ (Y or N). Sendi ng of SMS 6 for the GSM
models, or vocal message 2 f or PSTN line. Fi x t he pref erable waiting time b et we en 1 and 99 mi n. bef ore
sendi ng of the message. T he n ↵. Retur n to the dis play ABSENCE POWER SU PPLY. Go down wit h ↓.
5.4. 5-
6.1
PERIODICAL CALL See previous p oint. Adj ustable time laps e b et ween 1 and 999 ho urs. S endi ng of t ech nical mess age 9 or
vocal message 4.
5.4. 6
SIM EXP IRY See previo us point. Adj ustable time laps e b et ween 1 and 99 months. Sending of tech nical message 10 . 5.4. 7
POL. VOC. IN PUT ↵. 5.4. 8
POL. VOC.
INPUT 1
↵. Then s elect NO or NC with ↕. Confir m with ↵. Proc eed with the ot her vocal inputs from 1 to 4 and bloc ks
BL1 and BL2 (the blocks will have to be kept NC in case they are not used). Exit with ESC. GSM models:
proceed with th e menu P OLARITY SMS INPUT (from 1 to 10) (p ar. 5. 4.1 0).
TIME and DATE See the instruc tions on displ a y and c onfir m with ↵. 5.4. 11
SWITCHBOARD Teleph on e s witch board: enable or less t he function with ↕. Sel ect an out put number (0 to 9) followed fr om ↵.
Go d own to t he next menu with ↓.
5.4. 12
USER CODE
INSTALLER CODE
Access t he menu to modif y t he n c onfirm wit h ↵. 5.4.13
ANTISCANNER Enable or less with ↕ (Y or N) then ↵. Se nding of tec hnic al SMS 3 or vocal mess ag e 3. 5.4.14
SUPERVISION Enable or less with ↕ (Y or N) then ↵ . Sending of tec hnic al SMS 3 or vocal mess ag e 3. 5.4. 14
CANCELLATION Confirm with ↵, or ESC to exit. This operation will erase all programmings. 5.4.15
