R12000 CPU Upgrade Information
007-3725-002 13
18. Replace the faceplate by sliding it onto the system module, while at the same time
lifting slightly at the “V” to snap it in place (Figure 13).
When properly seated, the underside of the faceplate is flush to the module and the
screw holes are aligned.
Figure 13 Replacing the Face Plate
