Silver Eagle SE430 - Parts Breakdown

SE430 4 revised 10/15/15
SE430 Mini DA Sander
Ref. # Item # DESCRIPTION QTY.
1 RS43001 AirInlet 1
 2 RS43002 Spring 1
 3*RS43003A ValveStem 1
 4*RS43004A RubberSpacer 1
 7 RS43007 Screw(M3x8L) 1
 8 RS43008 Diffuser 1
 9 RS43009 Pin(2.5x25.8mm) 1
 10 RS43010SE MotorHousing 1
 11 RS43011 O-Ring(12.42x1.78mm) 1
 12 RS43012 Trigger 1
 13 RS43013 AirRegulator 1
 14 RS21114 BallBearing(626ZZ) 1
 15 RS43015 RearPlate 1
 16 RS43016 Rotor 1
 17 RS78816 RotorBlade 4
 18 RS43018 SpringPin(1.5x6mm) 1
 19 RS43019 Cylinder 1
 20 RS43020 RotorBushing 1
 21 RS43021A FontEndPlate(incl.#34) 1
 22 RS30524 BallBearing(608ZZ) 1
 23 RS43023 Connctor 1
 24 RS43024 Spacer 1
 25 RS43025 MotorLockNut 1
 26 RS43026 CounterBalance 1
27 RS43027 Nut 1
Ref. # Item # DESCRIPTION QTY.
 28 RS43028 BallBearing(608RS) 1
 29 RS43029 StopRing 1
 30 RS43030 Guard 1
 31 RS43031 RubberGrip 1
 32 RS43032 Key 1
 33 SE4302 2"Hook&LoopPad 1
  SE4303 3"Hook&LoopPad
 34  O-Ring(incl.with#21) 1
ReplacementDiscsAlsoAvailable:
SE4303320 3"SandingDisc320Grit
SE4303400 3"SandingDisc400Grit
SE4303600 3"SandingDisc600Grit
SE4302320 2"SandingDisc320Grit
SE4302400 2"SandingDisc400Grit
SE4302600 2"SandingDisc600Grit
AlsoAvailable:
RSSE430KCS BlowMoldedCaseonly
*Note:asofserialnumber8172001,#3RS43003Avalvestemand#4
RS43004Arubberspacerhavebeenmodified.Whenreplacingexisting
partswiththesenewpartsinoldertools,notethat#5RS43005valveand#6
RS43006o-ringarenolongernecessaryandshouldbediscarded.
