15
HARDWARE NEEDED (ACTUAL SIZE)
WASHER M10 X 30mm
2B-6795-00
10
(QTY. 1)
8. Insert Axle Rod (9), through Washer (10) and into
Wheel assembly and axle until it reaches the
other side of the Axle and wheel. Have a Second
person hold second Wheel.
NOTE
You may have to wiggle the Axle Rod (9)
up and down and side to side so it goes
through the second wheel.
DETAIL A
9
10
To Next Page
