16
1 3M-6850-00 4" Square Tube Plug (Pre-Installed) 1
2 1A-7686-02 Bottom Post 1
3 8S-6898-02 Top Post 1
4 901-28 3/8-16 Nylon Insert Locknut 14
5 3M-6883-00 1-1/4" OD Plastic Washer 8
6 8S-6630-01 Upper Board Arm 2
7 1B-6483-10 3/8-16 X 7.5" Hex Bolt-Grade 5 1
8 3M-6269-00 1/4" Spacer 2
9 3M-6548-00 1 X 2 Tube Plug 8
10 8S-6657-00 Stop Spacer 2
11 1A-6331-01 Lower Board Arm 1
12 NOT USED
13 3M-6467-00 Actuator Cap 1
14 8S-6658-00 Pivot Tube 1
15 3M-6542-00 Actuator Sleeve 1
16 4A-6605-00 Actuator 1
17 4L-7501-00 Height Decal 1
18 701-50 3/8 STD Washer 18
19 1B-6486-10 1/2-13 X 1-1/2" Hex Bolt 1
20 2B-6093-00 1/2 Flat Washer 2
21 2B-6095-00
1/2-13 Nylon Insert Locknut 1
22 1B-6484-10 3/8-16 X 7" Hex Bolt-Grade 5 3
23 6A-7404-01 Backboard Assembly-60x33” Glass 1
24 1B-6195-00 3/8-16 X 2.75" Hex Bolt 4
Key# Part # Description Qty. Key# Part # Description Qty.
25 1B-6485-10 3/8-16 X 5" Hex Bolt 2
26 2B-6114-00 3/8 Flat Washer 4
27 3M-6473-00 3X4 Rim Pad 1
28 6A-6374-00 Goal Assembly 1
29 3M-6835-00 Goal Spacer Plate (Pre-Installed)
30 2S-6795-01 Post Ear 2
31 Not Used
32 2S-6427-00 Rim Cover Plate 1
33 1B-6788-00 #8 x 1/2 Thread Forming Scr. 4
34 3M-6469-00 5/8 Thread Protector 4
35 2B-6097-00 5/8-11 Hex Nut 12
36 2B-6099-00 5/8 Split Lockwasher 4
37 2B-6098-01 5/8 SAE FLAT WSHR ZNC 8
38 2S-6453-00 Anchor T
.
emplate 1
39 2B-6112-00 5/8-11 X 14 "J" Bolt 4
40 1S-6167-00 #3 X 30" Rebar 4
41 7B-6255-00 Pull Pin 1
42 4A-6606-00 Actuator Handle 1
43 2L-7538-01 This Manual 1
44 3M-6580-01 48" Board Pad Right 1
45 3M-6581-01 48" Board Pad Left 1
46 Not Used
47 3F-6010-00 Net 1
48 3M-6564-01 Post Pad 1
49 1B-6782-00 3/8-16 x 1 3/4" Carriage Bolt 4
50 Not Used
77 1B-6821-00 Self Tapping Screw-#10 x 1 1/8" 10
2L-7538-01
1
B5402 REPLACEMENT PARTS LIST
- BACKBOARD -
Items needed to clean backboard:
- 100% cotton soft cloth, (only)
- Glass Cleaner
Clean backboard using a 100% Cotton soft cloth and glass cleaner. Clean glass as you would household windows. Strong cleansers will damage
backboard and void warranty.
– RIM –
HANGING ON THE RIM WILL VOID YOUR WARRANTY. Rims are not warranted for any defects other than workmanship. Torn back plates,
damaged springs, bent rings, damaged eye bolts, and torn or distorted rim supports result from hanging on the rim and are not warranted.
The goal should not be cranked under 7-1/2' or over 10'. Adjustments of the goal should be done under adult supervision.
When attempting slam dunk activity you should always wear a mouth guard to avoid dental injury.
SILVERBACK CARE INFORMATION
To ensure ease of operation, lubricate all pivot points at least every 6 months or as needed with a good lubricant such as WD-40.
Inspect your pole periodically, if rust should appear
, remove loose paint, sand lightly, primer and paint with exterior flat matte finish
enamel paint.
– –MAINTENANCE
– – RUST
1
(Pre-Installed)
(Pre-Installed)
(Pre-Installed)
