SilverCloud 850VA - TROUBLESHOOTING; LED and Sound Alert Issues; TECHNICAL SPECIFICATIONS

EN
7
TROUBLESHOOTING
LED/sound alert
Display Possible cause Solution
Only sound alert
“Battery” blinks Battery discharged Charge the battery
“LOAD” blinks Overload
Remove one or more
consumers
Sound alert and red LED on Faut code 02 ~ 58
Check the description
of the error code in
the table above
Remove the source of
the error according to
the table above
TECHNICAL SPECIFICATIONS
Capacity
850VA / 600W
Input
Voltage range
140 ~ 280 VAC ± 5%
Frequency range
50Hz / 60Hz
Output
Battery mode
230 VAC ± 5%
Line mode
200 VAC ~ 240 VAC
Transfer time
6ms
Wave form
Sine wave
Car battery
Voltage
12 V
Maximum charge current
20A
Capacity
30A - 200A
Other specications
Dimensions
420 x 280 x 225 mm
Weight
10.7 kg
Storage temperature
-26°C ~ +60°C
Working temperature
0 ~ +40 °C
Noise
≤ 60 dB
Communication interface
USB
Included accessories
Power cable 230V
Yes
Battery terminals
Yes
USB cable
Yes
CD software
Yes
