SPBS 5000 A1
Attaching the suction cups
NOTE
► To make sure that the suction cups
hold firmly, the surface
must be completely free of dust, oil and grease.
Variant A
Variant A is suitable for attaching the device to a flat, level surface.
♦ Attach all four suction cups
to the underside of the device,
as shown in “Figure A”.
♦ Push the suction cups
into the large holes.
♦ Now fasten the suction cups
by sliding them into the narrow
openings.
Figure A
♦ You can now attach the device on a flat, level using the suction
cups
.
