57 GB/MT
30° C /
80 % rH)
Noise level: 65 dB
Battery (remote
control):
2 x AAA 1.5 V
(LR03)
Weight: 21.2 kg
Protection type: IP20
(indoor use)
Permissible
operating
pressure
Discharge: 2.6 MPa
Suction: 1.0 MPa
Maximum
permissible
pressure
Discharge: 3.2 MPa
Suction: 1.2 MPa
Length of the
mains cable: approx. 1.8 m
Length of the hot
air outlet hose: approx. 1.5 m
Water tank
capacity: approx. 0.5 L
Dimensions
(L x W x H): approx. 33 x
28 x 69 cm
Window sealing
Circumference: 4 m
Scope of delivery
1 Mobile air conditioner
1 Remote control
2 Window feed-throughs
1 Hot air outlet hose
1 Hose connection (window)
1 Hose connection (air conditioner)
2 Fixing plugs
2 1.5 V batteries (type LR03 (AAA))
1 Window sealing
1 Set of operating and safety
instructions
Specific information on the model(s) which this
information relates to:
Designation Symbol Value Unit
Nominal power in cooling mode P
rated
in
cooling
mode
2 kW
