SAS 7.4 LI B3
2) Select a suitable installation location for the wall bracket 3:
It must be possible to remove the handheld vacuum cleaner easily and there
must be an accessible mains power socket for the mains adapter 4.
3) Drill two holes about 61 mm apart. Use the wall bracket
3 to mark the
holes, to ensure the correct spacing. The drill holes must be suitable for 5 mm
wall plugs.
4) Push the wall plugs
r into the holes and then screw the wall bracket 3
firmly into place using the screws e.
5) You can place the nozzles on the accessories holder on the side.
6) Connect the mains adapter
4 to a mains power socket.
Charging
NOTE
► Check to ensure that the on/off switch
6 has been pushed back (to the
position "0 ) before starting the charging process.
■ Place the handheld vacuum cleaner from above into the wall bracket
3 so
that the barrel plug
5 slips into the socket on the handheld vacuum cleaner.
The charge indicator lamp 7 flashes red and the charging process begins.
■ Important: The charge indicator lamp
7 lights up green once the handheld
vacuum cleaner is charged enough to vacuum again. This does not mean that
all the batteries are completely charged. When the charge indicator lamp 7
lights up green, the batteries are charged to around 80%.
■ When charging is complete, which can take around 5 hours with fully dis-
charged batteries, the appliance automatically switches to a trickle charge
(maintenance function). Nevertheless, in order to avoid possible damage
to the batteries, do not leave the appliance permanently connected to the
mains adapter
4.
■ Do not recharge the batteries again until the handheld vacuum cleaner’s
suction power becomes appreciably weaker and the charge indicator lamp
7
flashes green.
NOTE
► The handheld vacuum cleaner can also be charged directly via the mains
adapter
4. To do this, remove the barrel plug 5 with a slight twist from the
wall bracket 3 and insert it into the socket on the handheld vacuum cleaner.
