Wireless Doorbell SFK 16 A1
18 - English
Mounting the Transmitter
Look for a suitable place where you want to
mount the transmitter.
- Open the transmitter housing by inserting a
flat screwdriver into the notch on the
housing side. Carefully push the nose latch
(8) inwards. You can then remove the
upper housing piece.
- Drill two 5mm holes at a distance of 50mm
in the wall.
- Insert two of the supplied rawlplugs into
these holes.
- Place the two rubber rings into the recess
of the base plate.
- Insert two of the supplied screws through
the holes located in the bottom piece of the
transmitter housing and then screw them
onto the rawlplugs.
- Replace the upper housing piece by
pushing it onto the base unit piece.
