Assembly
Place the drum housing 1) 0 on the motor block such that the arrow points to
the opened lock .
Turn the drum housing 2) 0 anti-clockwise, so that the fi lling shaft w faces
upwards and the arrow points to the closed lock
. The drum housing 0
engages and is fi rmly seated.
Open the storage compartment 3) 7 and extract the required drum 3 4 5
6 q.
Fit the required drum 4) 3 4 5 6 q onto the drive shaft 9 in the drum
housing 0 and rotate it slightly clockwise so that it is securely seated.
WARNING! RISK OF INJURY!
Exercise caution in your interaction with the drums 3 4 5 6
q. The blades are very sharp!
NOTICE
When you wish to remove the drum, rotate the drum housing ► 0 so far that
it, together with the fi
tted drum, loosens itself from the motor block. Then
remove the drum from the drum housing 0. Fit the drum housing 0 as de-
scribed above back onto the motor block and insert the desired new drum.
Insert the plug into a mains power socket.5)
The appliance is now ready for use.
NOTICE
The drums which you do not need can, to save space and always have ►
handy, be stacked in the storage compartment 7. Pr
ess the lid of the storage
compartment 2 down a little at the markings
and simultaneously pull
it backwards. The lid 2 can now be lifted off . When re-attaching the lid 2
ensure that the restraints grip in the holes provided on the appliance.
!
