Fig. Step
E
INFO: Place the housing with the motor unit[7] on a flat surface to make the
assembly easier.
1. Remove the plastic cover from the motor shaft[].
2. Loosen the grille lock nut[5]: Turn the grille lock nut in anticlockwise direction.
3. Place the rear grille[6] on the motor shaft[].
4. Place the grille lock nut[5] on the rear grille[6].
5. Fasten the grille lock nut[5]: Turn the grille lock nut in clockwise direction.
6. Place the blade[4] on the grille lock nut[5].
7. Place the blade lock nut[3] on the blade[4].
8. Fasten the blade lock nut[3]: Turn the blade lock nut in anticlockwise direction.
F
1. Loosen the locking screw for the lower fastening bar[].
2. Open the lower fastening bar[].
3. Place the front grille[2] on the rear grille[6]. The upper fastening bar[1] must reach
into the rear grille.
4. Close the lower fastening bar[].
5. Secure the lower fastening bar[] with the locking screw for the lower fastening
bar[].
G
1. Insert the mist hose[] into the attachment of the mist hose on the housing of the
water tank[].
2. Insert the other side of the mist hose[] into the attachment of the mist hose on the
front grille[].
H
1. Remove the fixing screws[] and the washers[] from the base[].
2. Loosen the base connector[]: Turn the base connector in anticlockwise direction.
3. Place the housing with the motor unit[7] onto the base[].
4. Fasten the base connector[]: Turn the base connector in clockwise direction onto the
housing with the motor unit[7].
5. Insert the fixing screws[] through the washers[] into the pilot holes on the
underside of the base[].
I
1. Loosen the locking screw[].
2. Pull off the battery compartment cover[] towards the back.
3. Insert 2× 1.5V AAA batteries (LR03) according to the correct polarisation into the
battery compartment[].
4. Place the battery compartment cover[] on the battery compartment[].
5. Fasten the locking screw[].
INFO: Store the remote control[] in the recess on the top of the housing.
