SilverCrest USB 2.0 Video Grabber SVG 2.0 A2 English
9
Connection overview
Connect the adapter (5) to the Video Grabber (1). Put the connection adapter into the socket at the
back of the Video Grabber (see diagram).
Video Grabber
Connector Adapter
Snapshot Button
1
S-Video input
Stereo Audio input (white/red)
Composite Video input (yellow)
Connecting to your PC
In order to record using the Video Grabber you must first install the software. If you haven't already
done so, go to the chapter entitled 'Installing the software' and follow the instructions.
 Connect the adapter (5) to the Video Grabber (1) as shown in the earlier illustration.
1
This button generates a snapshot (photo of the current video) when the recording mode of the
enclosed 'Power Director' software is activated.

Silvercrest SVG 2.0 A2 Specifications

General

Brand	Silvercrest
Model	SVG 2.0 A2
Category	Media Converter
Language	English
