- 3 -
Technical data
a) Reception ranges:
FM (VHF): 87.5 – 108 MHz
AM (MW): 526.5 – 1606.5 kHz
SW 1-7 (KW): 5.95 – 15.6 MHz
b) Restrictions for climatic zones:
Temperatures: -5 – +40°C
Relative humidity: 20 – 80% relative humidity
c) Miscellaneous:
Output power: approx. 100 mW +/- 10%
Earphone connection: 3.5 mm jackplug socket
Max. output level f.
earphone socket: approx. 60 mV
Batteries: 2 x 1.5 V Type “AA” Mignon
Mains adaptor: optional, DC 3.6 V / 200 mA
Connection for mains adaptor: Barrel plug 3.5/1.3mm, plus innen
Dimensions: 123 x 35 x 75 mm
Weight : approx. 150 g (Radio, without batteries),
10 g Storage bag
d) Earphone:
Wideband characteristic
voltage (WBCV): 200 mV
Type: SWED100A1E
Impedance: 32 Ω
CE- Conformity
This device has been tested and approved in accordance with
the basic requirements and other relevent regulations of the EMV
directive 2004/108/EC.
