- 4 -
Appliance description
Figure A:
Telescopic antenna
"LIGHT" button: Switch display lighting on
POWER LED: indicates that the device is switched on
Waveband Selector Switch: Select FM, AM and SW reception ranges
Display
"MIN" button: Set the minutes
"POWER OFF" button: Switch the device off
"TIME" button: To set the time
"POWER ON" Button: Switch the device on
"HOUR" button: Set the hours
"ALARM" button: Set the alarm
"AL. ON/OFF" button: Switch the alarm function On/Off
Figure B:
Headphones connection socket
Power supply socket for AC adapter (optional)
Volume controller "VOL"
Figure C:
Slider switch "LOCAL/DX": Adjust reception sensitivity
Tuning regulator "TUNING"
Figure D:
Stand: Stand the device at an angle
Battery compartment
