12 GB/IE/NI
Start-up
Setting switching
times (Fig. A)
Use the switching pins
4
to set the times w
hen
you wish the timer to switch the connected
device on or off. Using a pointy object, e.g.
pen, push one or several pins down to lock
into place to set the desired switching time.
Every switching pin corresponds to a switch-
ing time of approx. 15 minutes.
Device for private use, set times may be offs
et.
Not suitable for applications requiring precise
and accurate switching.
In figure A the grey pins mark a switching
time of 8:30 pm to 10:30 pm. A load is
switched on during the time from 8:30 pm
to 10:30 pm.
